Page 11
7.2 GPS module install
GPS receiver module has integrated plate type GPS
passive antenna with stronger reception ability shielding the
false signal by ground reflection efficiently. DO NOT install
next to metal or carbon fiber & other shielding material, which
may block satellite signal reception. Install the GPS Module
horizontal and away from electromagnetic sources such as
ESC‘s, power wires, servo wires & video transmitters which can interfere with GPS signal.
7.3 Power manager module install
Power manager module supports 2S
～6S lithium battery
input. The integrated current sensor can measure APM draw and
voltage; DC-DC module offers 5V to FY-41AP meanwhile 12V to
video camera and video transmitter. But servo power is supplied
by ESC or S1~S8 any port access.
7.4 Power manager module install
The airspeed sensor need to pull ahead the front of the pneumatic opening and in the
line with the direction of flight, cannot tilt . You can install the Airspeed sensor to the wing
or in the front of the nose, do not block the front of the air inlet , we can use the glue to fix
the airspeed sensor.But can't completely obturate the end of the airspeed sensor ,to
maintain pressure connected with the outside world. Note: Make sure that after installation,
the fuselage in flight airflow can not interfere with air intakes.
Static Pressure Port Dynamic Pressure Port
