D-16
Setting the Monitor Type
Using the list in the example above, you can set the monitor type for
graphics slot 0 by typing the following:
Configuration Menu: Enter command > monitor graphics0 Enter
NOTICE: You can exit at this point by entering x, and the
monitor type will not be changed.
The screen displays the choice of supported monitors, similar to the
following. Follow the directions in the screen prompts and enter the
monitor type you want to configure (in this example, number 1).
MONITOR INFORMATION
Type Resolution Frequency
–––– –––––––––– –––––––––
1 1280x1024 72Hz
2 1024x768 75Hz
3 1024x768 70Hz
4 1024x768 75Hz Flat Panel
5 1280x1024 60Hz
6 1024X768 60Hz
7 640X480 60Hz
8 1280X1024 75Hz VESA
9 1024X768 75Hz VESA
10 800X600 75Hz VESA
11 640X480 75Hz VESA
12 1280X1024 72HZ GrayScale
13 1280X1024 50HZ
Enter monitor type selection from list above (or ’x’ to exit): 2
2 1024x768 75Hz
Press to save this monitor type or to exit monitor selection: y
