Maintenance

FTB-500

267

Recharging the Batteries

Recharging the Batteries

Your unit uses smart lithium-ion (Li-Ion) batteries. The number of batteries
that power your unit and that come with it depends on the model that you
have purchased. There are two batteries for the four-slot model, and three
batteries for the eight-slot model.

The charge status is shown in the taskbar (at the left of the clock).
Simply tap the battery icon for more information.

The unit also indicates the charge status with the LED on its front panel
(see LED Indicators Description on page 8).

C

AUTION

For the four-slot units: Only charge the batteries with the AC
adapter/charger provided by EXFO with your unit.

For the eight-slot units: These units can be connected to the AC
power using a standard three-wire power cord.
