Introducing the FTB-500

8

FTB-500

LED Indicators Description

LED Indicators Description

The LED panel on the front of the unit provides you with the status of the
FTB-500.

LED

Status

Meaning

Green

Unit is on.

Green, blinking Unit is in Sleep mode.
Off

Unit is off or in Hibernation mode.

(when unit is

connected to an

external power

source)

Green

All batteries are fully charged.

Green, blinking At least one battery is charging.
Yellow, blinking No battery present in the unit.

OR
The unit and its modules would be

using more power than what is

available from batteries. Do not

disconnect AC power while this

module is in use.
A blinking yellow LED takes

precedence over a blinking green one,

so when AC power is connected, even

if the LED is blinking yellow, batteries
are probably charging (depending on

conditions).
