Working with Your Unit

116

FTB-500

Taking Screen Captures

To take a screen capture:
1.
If necessary, from the front panel of the unit, press the

button to

show the taskbar.

2. From the notification area, tap the camera icon.

3. From the shortcut menu, tap Take a screenshot.

The screen capture is automatically taken (a visual effect typical of a
camera taking a picture indicates that the capture is complete).

Note: If a keyboard is connected to your unit, you can also press the Windows

logo key + PRINT SCREEN.

Note: If you tap Exit from the shortcut menu, you will need to log off, and then log

on to be able to take screen captures again.
