EXFO FTB-500 User Manual
Page 18
Introducing the FTB-500
10
FTB-500
LED Indicators Description
Green
Result status from application currently
displayed.
Pass (result does not exceed the
defined threshold).
Green, blinking Result statuses from two or more
applications.
Pass (no results exceed the defined
threshold).
Red
Result status from application currently
displayed.
Fail (result exceeds the defined
threshold).
Red, blinking
Result statuses from two or more
applications.
Fail (all results exceed the defined
threshold).
OR
Mixed statuses (some are Pass and
some are Fail).
Green
Unit is controlled remotely.
LED
Status
Meaning
