EXFO FTB-500 User Manual
Page 267

Using FTB Products in an Automated Test Environment
FTB-500
259
Monitoring Remote Commands
3. Do one of the following:
If monitoring using ActiveX or RS-232, click Connect to IC.
You are automatically connected to the monitoring system. The
Disconnect from IC button becomes available for you when you
are ready to disconnect.
Once connected, your current connection information will appear
in the upper part of the window, and the commands will appear as
a list in the lower part of the window.
With the History parameter, you determine how many commands
you want to keep in the list. You can change the number by using
the arrow buttons on each side of the list.
To clear the history, click
.
To view the list in any word processor, click
to copy it to the
clipboard, and then paste it in your document. You can use any
program, as the list is copied in text format.
To exit the monitoring utility, click Exit.
For more information, see the section on using your unit in an
automated test environment.
Connection
information
Incoming
commands
