Managing Data

FTB-500

153

Using the USB to RS-232 Adapter

To use the USB/RS-232 adapter:
1.
Turn on both the unit and the serial device.

2. Connect as shown. You can connect the USB end of the adapter to any

of the USB ports.

Note: If the device that you want to use is a computer (not equipped with USB

ports) you may want to use a null-modem serial cable as an “extension
cable” between the device and the USB/RS-232 adapter.

The adapter will be detected automatically on your unit.

Serial

device

Serial end

USB/RS-232

adapter

USB end

FTB-500
