Multifunction Loss Tester
1
1
Introducing the FOT-930
Multifunction Loss Tester
The FOT-930 Multifunction Loss Tester integrates a power meter and light
sources with an optical return loss meter, optional talk set and visual fault
locator.
Main Features
The unit features F
AS
T
ES
T™, EXFO’s one-touch automated measurement.
In 10 seconds, you can simultaneously test IL and ORL at up to four
wavelengths, in both directions. During the same test, the unit also
determines fiber length.
The power meter has the following characteristics:
Ge, GeX or InGaAs detector with 40 calibrated wavelengths to measure
absolute power or link loss
Editable list of favorite wavelengths for easy access
Modulated signal detection
Automatic wavelength detection from compatible sources
No offset nulling required in normal operation
DC connector
Battery charge
status LEDs
RS-232 connector
Shoulder strap eyelet
Stand
Display
Keypad
