Managing Test Results

56

FOT-930

Checking Available Memory

Checking Available Memory

You can save up to 1024 results in the unit memory.

To view the available memory on your unit:
Press Menu, then select Results/Information > Unit Info.

Transferring Test Results to a Computer

Using an appropriate serial cable and the Handheld Data Transfer software,
you can transfer results from your handheld unit to a computer or FTB-500.
This way, you can increase storage capacity, perform better analyses on
test results and create reports.

To transfer test results to a computer:
1.
Using the serial cable, connect your unit to an available COM port of

the computer.

Note: If your computer is not equipped with an RS-232 port, you can use a USB

adapter. After installing the proper drivers, your computer should associate
the adapter to an available COM port.

I

MPORTANT

Transferred files are not automatically deleted from your unit.

Serial port

(male DB9)

RS-232

connector
