Performing Automated IL/ORL/Length Measurements (F

AS

T

ES

T

)

52

FOT-930

Performing the

F

AS

T

ES

T

Performing the F

AS

T

ES

T

Although F

AS

T

ES

T requires two units (one at each end of the fiber under

test), you initiate it from only one (the master). Both units use F

AS

T

ES

T

settings from the master unit.

To perform a F

AS

T

ES

T:

Unit A (Master)

Unit B

1. If necessary, null the offsets (see

Nulling Electrical Offsets on page 32).

1. If necessary, null the offsets.

2. Clean your fibers properly (see

Cleaning and Connecting Optical
Fibers
on page 22).

2. Clean your fibers properly.

3. Set up the F

AS

T

ES

T (see Setting Up the

FasTesT on page 48).

4. If you are testing ORL, perform an

ORL zero measurement from the ORL
Meter
pane (see Performing ORL
Reference and Setting ORL Zero Value

on page 42).

3. If you are testing ORL, perform an

ORL zero measurement from the ORL
Meter
pane.

5. Reference your unit (see Referencing

Units for FasTesT on page 49).

4. Reference your unit.

6. Connect reference patchcord to fiber

under test (as shown):

5. Connect reference patchcord to fiber

under test (as shown):

Reference

patchcord

Fiber

under test

Reference

patchcord

Bulkhead

adapter

Bulkhead

adapter
