Multifunction Loss Tester

93

A Technical Specifications

I

MPORTANT

The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com
.

EXTERNAL POWER METER

Specifications

a

FOT-932

FOT-932X

FOT-933

Detector type

Ge

GeX

InGaAs

Measurement range (dBm)

10 to –70

26 to –55

6 to –73

Range displayed (dBm)

Down to –77

Down to –65

Down to –80

Uncertainty

b, c

± 5 % ± 0.1 nW

± 5 % ± 3 nW

± 5 % ± 0.05 nW

Wavelength range (nm)

800 to 1650

800 to 1650

800 to 1650

Display resolution (dB)

b

0.01

0.01

0.01

Calibrated wavelengths

40

42

40

Recommended recalibration period (years)

3

3

3

Automatic offset nulling

d

Yes

Yes

Yes

Measurement-distance units

kilometers, meters, kilofeet, feet, miles

SOURCES

Standard

-4

-5

-12C (second port)

-12D (second port)

Wavelengths

(nm)

e

1310 ± 20

1310 ± 20

1310 ± 20

850 ± 25

850 ± 25

1550 ± 20

1550 ± 20

1490 ± 10

1300 +50/–10

1300 +50/–10

1625 ± 10

1550 ± 20

Emitter type

Laser

Laser

Laser

LED

LED

Minimum output power (dBm)

e

–1/–1

–1/–4/–7

–1/–7/–4

–27/–27 (50/125 μm)

i

–21/–21 (62.5/125 μm)

i

Spectral width (nm)

f

) 5/) 5

) 5/) 5/) 5

) 5/) 5/) 5

50/135

50/135

Stability (8 hours) (dB)

g

± 0.05

± 0.05

± 0.05

± 0.05

± 0.05

FASTEST

Standard

-4

-5

-12C (second port)

-12D (second port)

Wavelengths (nm)

1310

1310

1310

850

850

1550

1550

1490

1300

1300

1625

1550

Loss range (dB)

h

60

56

56

40

46

Loss precision (repeatability) (dB)

i

side-by-side 0.15

0.15

0.15

0.15

0.15

loopback

0.25

0.25

0.25

0.25

0.25

Length measurement range (km)

200

200

200

5

5

Length measurement uncertainty

j

±(10 m + 1 % x length)

DEDICATED ORL

All SM Wavelengths

ORL range (APC / UPC) (dB)

65/55

ORL uncertainty (dB)

k

± 0.5

Resolution (dB)

b

0.01

TALK SET

Emitter type

Laser

Wavelength (nm)

1550 ± 20

Dynamic range at 1550 nm (dB)

45

Dynamic range MM (dB)

l

40

VFL

i

Emitter type

Laser

Wavelength (nm)

650

Output power (dBm)

3
