Data Analysis
Copper, VDSL2, ADSL2+, and IP Triple-Play Test Set 219
Saving Results
Saving Results
Save Result
The Save Result tab allows you to save your test results to a file or to an
HTML report.
The available entries are the following:
³
Save as Type lists the following
formats to save your test results:
³
AXS200 format is a binary file
format with ext *.dat. This
format can be opened only on
an AXS200 unit. The Available
Graphs list box will be
unavailable in this case.
³
*.csv saves only graphical results.Textual results must be formatted
as a comma-separated values table for easy importation to Excel.
Results are saved to a USB.
³
*.gif stands for graphics interchange format and is one of the most
common file formats for graphic images on the World Wide Web.
Results are saved to a USB.
³
*.bmp saves graphical results in a bitmap file format. Results are
saved to a USB.
³
*.xml saves your data in a common language format to share on
the Web.
³
Available Graphs is enabled only if the selected format under
Save as Type is *.gif, *.csv, or *.bmp. For a test that does not have a
graph, this list box is unavailable.
³
Save Results button saves the test results in internal or external
memory (depending on the Save as Type format).
