Configure Tests for DSL/IP Triple-Play Verification
150 AXS-200/635
Configure Profile
Configure Profile
Before configuring all the line test parameters, you can refer to previously
saved profiles.
Select Configuration
The Select Config tab allows you to setup and store multiple profiles
containing specific configuration parameters for the unit. At power up, all
test configuration parameters are read from the last current test
configuration.
³
Read from File allows you to view
a list of previously saved profiles
with the first entry being Default.
³
Save to File allows you to save
test parameters to a default profile
or a new custom file name.
To select test configuration
parameters to be used during
DSL/IP tests:
1. From the Select Config tab pane, use the up/down arrows to highlight
an old or new configuration file name.
2. Press to confirm the selection.
3. Press the left arrow to highlight the Read from File button.
4. Press to confirm the selection.
5. Press the up/down arrows to highlight the text edit box.
6. Use the alphanumeric keypad to enter a custom profile name.
7. Press the left arrow to highlight the Save to File button to save the
configured profile.
