Copper, VDSL2, ADSL2+, and IP Triple-Play Test Set 133
10 Connection Setup for DSL/IP
Triple-Play Verification Tests
The purpose of the Connection Setup function is to configure the unit for a
series of connection parameters for Auto Test and CPE testing, and IPTV,
data, and VoIP analyses. These parameters are accessible through the
different pane tabs.
To configure the connection parameters during DSL/IP tests:
1. From the DSL/IP Tests pane, use the up/down arrows to select the
Connection Setup entry.
2. Press to confirm the selection.
To view the available tabs:
Press the left/right function arrows on each side of the F1, F2, and F3 keys.
Setup Profile
Profiles can be created and stored in the internal memory for later use.
They can also be stored externally or exported to another unit via a USB
memory device or HyperTerminal. You can easily load an external profile
through the USB port and a HyperTerminal.
