Connection diagram, Result – EXFO VDSL2 User Manual
Page 102
Fault Location Tests
94
AXS-200/635
RFL Single Pair (2 wire) Test
Connection Diagram
The Connection Diagram tab displays
how to connect the cables to the unit.
The green lead is used as reference.
Continue button allows you to resume
the test once the cables have been
connected.
Result
The Result tab allows you to view
detailed results of the RFL test.
