Connection Setup for DSL/IP Triple-Play Verification Tests
142
AXS-200/635
Setup Line Connection
³
DNS2 is the address of the secondary domain name server to be used
by the unit. If DNS is unavailable, enter 0.0.0.0.
³
Local MAC Address is the internal MAC address of the unit: either
AXS200 or User Defined.
³
MAC Address is a specific MAC address, maximum 17 characters, if
you select User Defined for the previous parameter.
When the AccessMode selection is set
to Routed PPPoE or Routed PPPoA,
the available parameters are the
following:
³
Obtain IP is either Dynamic
where the access concentrator or
broadband remote access server
assigns a temporary IP address to
the unit, or Static where you enter
the IP address of the unit.
³
Static IP is the address of the current location assigned by the service
provider. This entry is unavailable if Obtain IP is set to Dynamic.
³
Login Name is your user ID.
³
Password is your user password.
When the AccessMode selection is set
to Routed IPoA, the available
parameters are the following:
³
IP Address is the address for the
unit that is actively connected to
your network or the internet at the
time of login.
³
Gateway is the IP address of the
default gateway.
