Connection Setup for DSL/IP Triple-Play Verification Tests
Copper, VDSL2, ADSL2+, and IP Triple-Play Test Set 143
Setup Line Connection
³
Subnet Mask is the network address used to identify if the IP address is
within the same wide area network.
³
DNS1 is the address of the primary domain name server to be used by
the unit. If DNS is unavailable, enter 0.0.0.0.
³
DNS2 is the address of the secondary domain name server to be used
by the unit. If DNS is unavailable, enter 0.0.0.0.
Note: WAN IP setup is not required when Access Mode is set to Bridged. The line
encapsulation setting defines the parameters required.
To select the WAN IP parameters to configure:
1. From the Connection Setup pane, press the left/right function arrows
until the WAN IP tab is displayed.
2. Press the F1, F2, or F3 key located just below the tab to select it.
3. Press the up/down arrows to select the desired parameter.
4. Press to open the list or modify the parameter.
5. In the list, press the up/down arrows to select the function or mode.
OR
Use the alphanumeric keypad to enter the value you want to specify.
6. Press to confirm the selection.
