Upgrading The Computer

Upgrading the Optical (CD/DVD) Device 6 - 7

6

Upgrading the Optical (CD/DVD) Device

1.

Turn off the computer, and turn it over and remove the battery.

2.

Locate the RAM & CPU bay cover and remove screws

-

.

3.

Carefully (a fan and cable are attached to the under side of the cover) lift up
the bay cover.

4.

Carefully disconnect the fan cable

, and remove the cover

.

Figure 6 - 6

Removing the RAM

& CPU Bay Cover

1

4

5

6

5

6

3

4

2

1

Fan Cable

Make sure you reconnect the fan cable

before screwing down the bay cover.

5
