1 - 14 System Map: Right View
Quick Start Guide
1
System Map: Right View
Figure 1 - 7
Right View
1. Optical Device
Drive Bay (for CD/
DVD Device - see
page
2 - 3 )
2. 1 * USB 2.0 Port
3. GPS Antenna
Socket (for optional
GPS Module)
4. Serial (COM1) Port
5. Security Lock Slot
1
2 4 3
Changing DVD Regional Codes
Go to the Control Panel and double-click De-
vice Manager (Hardware and Sound), then
click the + next to DVD/CD-ROM drives.
Double-click on the DVD-ROM device to
bring up the Properties dialog box, and se-
lect the DVD Region (tab) to bring up the
control panel to allow you to adjust the region-
al code (see
“DVD Regional Codes” on
page 2 - 5 ).
DVD region detection is device dependent,
not OS-dependent. You can select your mod-
ule’s region code 5 times. The fifth selection
is permanent. This cannot be altered even if
you change your operating system or you use
the module in another computer.
Disk Eject Warning
Don’t try to eject a CD/DVD while the system is
accessing it. This may cause the system to
“crash”. Stop the disk first then eject it, or press
the stop button twice.
CD/DVD Emergency Eject
If you need to manually eject a CD/DVD (e.g.
due to an unexpected power interruption) you
may push the end of a straightened paper clip
into the emergency eject hole. Do not use a
sharpened pencil or any object that may break
and become lodged in the hole. Don’t try to re-
move a floppy disk/CD/DVD while the system is
accessing it. This may cause the system to
“crash”.
