Upgrading The Computer
6 - 8 Upgrading the Optical (CD/DVD) Device
6
5. Remove screws - and use a screwdriver to carefully slide out the optical
device at point .
6. Insert the new device and replace the optical device screws - .
7. Reconnect the fan cable before replacing the bay cover ( in Figure 6 - 6 on
page 6 - 7 ).
8. Replace the bay cover and screws.
7 9
10
7 9
5
9
8
7
10
Figure 6 - 7
Removing the
Optical Device
