Upgrading The Computer
Upgrading the System Memory (RAM) 6 - 9
6
Upgrading the System Memory (RAM)
1. Turn off the computer, and turn it over and remove the battery.
2. Locate the RAM & CPU bay cover and remove screws - .
3. Carefully (a fan and cable are attached to the under side of the cover) lift up
the bay cover.
4. Carefully disconnect the fan cable , and remove the cover .
System Memory
The computer has one
memory socket for 200
pin Small Outline Dual
In-line (SO-DIMM)
DDRII (DDR2) type
memory modules (see
“Memory” on page C -
2
for details of support-
ed module types).
The total memory size is
automatically detected
by the POST routine
once you turn on your
computer.
Figure 6 - 8
Removing the RAM
& CPU Bay Cover
1 4
5 6
5
6
3
4
2 1
Fan Cable
Make sure you reconnect the fan cable
before screwing down the bay cover. 5
