Interface Related Features
4-18 QuickScan ® QS6500/QS6500 BT
RS-232 Interface Features — cont.
ACK Character
START
MODE BARCODE
Sets the ACK character from the set of ASCII charac-
ters or any hex value from 0 to FF. To configure this
feature, scan the “START” bar code above to place
the unit in Programming Mode, then the “Set ACK
Character,” followed by the digits from the Alphanu-
meric table in
Appendix B, Alpha-Numeric Pad
representing your desired character. Accept your
selection by scanning the “SET” bar code below and
finally, exit programming mode by scanning the
“END” barcode below.
DEFAULT SETTING FOR THIS FEATURE: 06 (0x06)
Set ACK
Character
SET
END
