Getting Started
49
MXC-6300
2.6
Connecting DC Power
The DC power input connector of the MXC-6300 has V+, V- , and
chassis ground pins, and accepts input voltage as shown previ-
ously. Connect DC power as shown. Two screws fasten to secure
the plug.
WARNING:
Before connecting DC power to the MXC-6300, ensure voltage
and polarity are compliant with the DC input. Improper input
voltage or polarity can cause system damage.
