Introduction 11
MXC-6300
Table 1-1: Front Panel I/O Connector Legend
1.5.1 Power Button
The power button is a non-latched push button with a blue LED
indicator. System is turned on when the button is depressed, and
the power LED lights. If the system hangs, depress the button for
5 seconds to turn off the system completely.
1.5.2 LED Indicators
In addition to the LED of the power button, three LEDs on the front
panel indicate the following.
Table 1-2: LED Indicators
G Gigabit Ethernet P PCI express x8 Slot
H CFast (Push-Push, Type II) Q PCI express x16 Slot
I DVI-I connector R
Reserved space for dual-
slot width PCIex16 graphic
card
NOTE: NOTE:
1 PCIe x16 + 1 PCI expansion slot, with PCIe x16 signal con-
verts to PCIe x8 if two PCI x8 cards are installed in P+Q slots
LED indicator Color Description
Watchdog (WD) Yellow
Indicates watchdog timer status. When
watchdog timer starts, the LED flashes.
When the timer is expired, the LED
remains lit..
Hard disk drive
(HD)
Orange
Indicates the HDD operating state.
When the SATA hard drive or CFast card
is active, the LED indicator flashes.
Diagnostic (DG) Green
When lit continuously, indicates no
physical storage is connected, and if
blinking, indicates no memory is
installed on either SODIMM socket.
