Introduction
23
MXC-6300
Table 1-9: DisplayPort Pin Assignments
Table 1-10: Applicable Cable Types
Display Options
With computing and graphic performance enhancement by its 3rd
generation Intel processor, the MXC-6300 controller can support
three independent displays, with configuration as follows.
Pin
Signal
Pin Signal
1
CN_DDPx0+ 11
GND
2
GND
12
CN_DDPx3-
3
CN_DDPx0-
13
CN_DDPx_AUX_SEL
4
CN_DDPx1+ 14
CN_DDPx_CONFIG2
5
GND
15
CN_DDPx_AUX+
6
CN_DDPx1-
16
GND
7
CN_DDPx2+ 17
CN_DDPx_AUX-
8
GND
18
CN_DDPx_HPD
9
CN_DDPx2-
19
GND
10
CN_DDPx3+ 20
+V3.3_DDPx_PWR_CN
P/N
Description
30-01119-0000 Passive DisplayPort to HDMI adapter cable
30-01120-0000 Passive DisplayPort to DVI adapter cable
30-01121-0000 Passive DisplayPort to VGA adapter cable
30-01157-0000 Active DisplayPort to DVI adapter cable
DisplayPort1
DisplayPort2
Other Ports
DisplayPort
2560x1600, 60Hz
DisplayPort
1920x1200, 60Hz
DVI
1920x1200, 60Hz
DisplayPort
2560x1600, 60Hz
DisplayPort
1920x1200, 60Hz
VGA
1920x1200, 60Hz
DisplayPort
2560x1600, 60Hz
DisplayPort
1920x1200, 60Hz
LVDS
1920x1200, 60Hz
