10 Introduction
1.5 Front Panel I/O Connectors
Figure 1-7: Front Panel I/O Connectors
A Power Button J COM port x4
B LED Indicators K DisplayPorts
C Reset Button L Audio Jacks
D Digital I/O connector M PS/2 Keyboard & Mouse
E USB 2.0 x2 (Type A) N DC power supply
F USB3.0 x4 (Type A) O 5V 32-Bit PCI Slot
A
B
C
D
E
F G
H
I
J
K
L
M N Q R P O
