30 Introduction
Table 1-18: +5V and +12V Connector Pin Functions
1.7.3 Internal CFast Card Connector
An internal Type II push-push CFast socket connects to the host
controller by SATA interface. Data transfer rates up to 3.0Gb/s
(300MB/s) / 1.5Gb/s (150MB/s) are supported. The host SATA
controller provides a legacy operating mode using I/O space, and
an AHCI operating mode using memory space. The CFast card
can function as a storage device for system installation. Installa-
tion of a CFast card is described in Section 2.4:Installing CFast
Cards.
2 GND
3 GND
4 +5V
Pin Signal
