OTHER CONNECTIONS
SEHING THE SLEEP TIMER
The unit can be turned off automatically at a specified time.
Use the remote control.
1 Press the SLEEP button.
Gi]
'to
2 Within 4 seconds, press the ◄◄ or ►► button
to specify the time untii the power is turned off.
Each time the button is pressed, the time changes between
10 and 240 minutes in 10-minute steps.
Specified time
Fol
» I f f f f
To check the time remaining until the power is turned off
Press the SLEEP button once. The remaining time is displayed
for 4 seconds.
To cancel the sleep timer
Press the SLEEP button twice so that “SLEEP” on the display
disappears.
CONNECTING OPTIONAL
EQUIPMENT
Refer to the operating instructions of the connected equipment
for details.
• The connecting cords are not supplied. Obtain the necessary
connecting cords.
• Consult your local Aiwa dealer for optional equipment.
VIDEO/AUX JACKS
This unit can input analog sound signals through these jacks.
Use a cable with RCA phono plugs to connect audio equipment
(turntables, LD players, VCRs, TV, etc.).
Connect the red plug to the R jack, and the white plug to the L
jack.
When connecting a turntabie
Use an Aiwa turntable equipped with a built-in equalizer amplifier.
LINE OUT JACKS
This unit can output analog sound signal through these jacks.
Use a cable with RCA phono plugs to connect audio equipment
with LINE IN (analog input) jacks.
CD DIGITAL OUT (OPTICAL) JACK
This unit can output CD digital sound signals through this jack.
Use an optical cable to connect digital audio equipment (digital
amplifier, DAT deck, MD recorder, etc.).
Remove the dust cap
(D from the CD DIGITAL OUT (OF’TICAL)
jack. Then, connect an optical cable plug to the CD DIGITAL
OUT (OPTICAL) jack. '
When the CD DIGITAL OUT (OPTICAL) jack is not being
used
Attach the supplied dust cap.
SUPER WOOFER < JACK
Connect an optional powered sub woofer v/ith a built-in-amplifier
to the jack.
ENGLISH
20
