Models 390 and 395
390 AND 395 LAWN TRACTORS
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1 712-0429 Hex Ins. L-Nut 5/16-18 Thd. 43 712-0287 Hex Nut 1/4-20 Thd.
2 735-0126 Rubber Wash. .33 I.D. x .87 44 761-0147 Blade Brake Ass’y.
O.D. 45 726-0121 Push Cap .250 Dia.
3 08118 Grip Finger—Black 46 710-0198 Hex Sems Scr. 5/16-18 x
4 749-0212 Lift Handle—R.H. .75" Lg.
5 13630 Lift Handie Brkt. Ass’y. 47 761-0130 Disc Brake Ass’y.—Comp.
6 736-0219 Belleville Wash. .40 I.D. x 48 HH-02-03631 Hex Lock Nut
1.13 O.D. 49 HH-03-03032 Washer
7 710-0201 Hex Hd. Cap Scr. 3/8-16 x 50 HH-18-03493 Cam Lever
.62" Lg.* 51 HH-05-03034 Push Pin
8
—
Engine 52 HH-03-03303 Disc Backup
9 710-0442 Hex Hd. Cap Scr. 53 HH-15-02124 Friction Pad 1.110" Dia. x
5/16-18 X 1.50" Lg.* .472 Thk.
10 13851 Lockout Link Ass’y- 54 710-0176 Hex Hd. Cap Scr. 5/16-18
11 714-0115 Cotter Pin 1/8" Dia. x 1.00" X 2.75" Lg.
Lg.* 55 761-0133 Spacer for Disc Brake .322
12 736-0192 ^ FI-Wash. .531 I.D. x .93 O.D. I.D.
X
.38" Lg.
13 44024/AS I t Handle Pivot Brkt. 56 11010 Brake Plate
14 735-0195 Rubber Wash. 57 HH-12-03292 Casting—Carrier Side
15 736-0237 Flat-Wash. 58 HH-15-03149 Friction Pad 1.110" Dia. x
16 748-0273 Spacer .632 I.D. x .88 O.D. .245 Thk.
17 717-0416 Three Speed Trans.—Comp. 59 HH-12-03292 Casting—Cam Side
18 747-0172 Shift Lever 60 717-0318 Differential Ass’y. Comp.
19 720-0165 Bail Knob 61 712-0158 Hex Cent. L-Nut 5/16-18
20 710-0134 Carriage Bolt V4-20 x .62" Thd.
Lg.* 62 732-0157 Spring .380 O.D. x 3.25"
21 14219 Brake Pedal Ass’y. Lg. (Brake Return)
22 738-0140 Shid. Scr. .431 Dia. x .18" 63 747-0107 Brake Rod .250 Dia. x
Lg- 24.12" Lg.
23 732-0191 Spring (Idler) .75 O.D. x 64 710-0627 Hex Scr. w/Lock 5/16-24 x
11.0" Lg. .750" Lg.
24 712-0116 Hex Ins. L-Nut 3/8-24 Thd. 66 734-0521 Rear Wheel—Rim Ass’y.
25 12446 Idler Brkt. Ass’y. Less Tire
26 732-0245 Brake Spring 67 734-0427 Rear Wheel—Tire Only
27 726-0100 Push Nut 3/8" Dia. Rod 15.0 X 6.0
28 11061 Clutch Rod 68 736-0134 FI-Wash.
29 11057 Clutch Lockout Lever Ass’y. 69 741-0199 Flange Brg.
30 14220 Clutch Pedal Ass’y. 70 710-0437 Chain Adj. Link 5/16-18 Thd.
31 735-0201 Foot Pad (Clutch and 71 11009 Rear Axle Brkt.
Brake) 72 713-0104 #41 Chain 1/2 Pitch x 63
32 12654 Engine Belt Guard Ass’y. Links
33 736-0242 Belleville Wash. .345 I.D. x 73 10364 Rear Axle Plate
.88 O.D. 74 10360 Axle Bolt Plate Ass’y.
34 738-0215 ShId. Bolt .498 Dia. x 3.00" 75 11011 Disc Brake Brkt. Ass’y.
Lg- 76 11024 Deck Link
35 736-0119 L-Wash. 5/16" Scr.* 77 09721 Pivot Link Ass’y.
36 712-0267 Hex Nut 5/16-18 Thd.* 78 11014 Connecting Lift Brkt.
37 710-0259 Hex Sems Scr. 5/16-18 x 79 714-0101 Int. Cotter Pin 1 / 2 " Dia.
.62" Lg.* 80 11023 Deck Link Ass’y. (3 Req’d.)
38 12160 Belt Keeper Ass’y. 81 711-0332 Left Brkt. Pin
39 10426 Belt Keeper Ass’y. 82 11249 Ht. Adj. Knob
40 738-0373 Shid. Bolt .498 Dia. x 1.525" 83 11027 Handle Stop Brkt. Ass’y.
Lg. 84 12934 Reinforcement Brkt.
41 11039 Pedal “U” Brkt. Ass’y. 85 749-0466 Reinforcement Brkt.
42 11056 Parking Brake Lever Ass’y. 86 HH-06-03031 Spring
WHEEL CHART
Front Wheel Rear Wheel
PART
NO.
DESCRIPTION
PART-----
NO.
DESCRIPTION
734-1044 Wheel Ass’y. Comp. 11.0 x 4.0 734-0524 Wheel Ass’y. Comp. 15.00 x 6.00
734-1042 Rim Ass’y. 734-0521 Rim Ass’y. with Hub
734-0770 Tire Oniy 11.0
X
4.0 734-0427 Tire Only Tubeless 15.00 x 6.00
741-0313 Flange Brg. Front Wheel 741-0199
734-0255 Bearing—Rear Wheel
Air Valve
