PC ADJUSTMENT
This projector can automatically detect most display signals from most persona! computers currently distributed.
However, some computers adopt a special signal format which is different from the standard one and the projector
"'■^.nnot detect it. If this happens, the projector cannot reproduce a proper image. And a flickering picture, a
n-synchronized picture, a non-centered picture or a skewed picture may be projected instead.
For those non-standard formats, this projector is provided with PC ADJUST, enabling you to precisely adjust several
parameters to match with the input signal format. The projector has eight independent memory areas where you can
store the parameter you have set. This enables you to recaithe setting for a specific computer when you need it.
1. Press the MENU BUTTON and the MAIN MENU DISPLAY dialog box will appear.
2. Press the POINT LEFT/RIGHT BUTTON(s) to select PC ADJUST and press the SELECT (REAR CLICK}
BUTTON. Another dialog box ” Where to reserve” will appear,
3. In this dialog box, you will select one of the memory areas from among "Mode 1" to "Mode 8”. If parameters have
been previously set and stored in the memory, the status "Stored” will appear on the corresponding row. If not,
"Free" will appear.
4. Press the POINT DOWN BUTTON and a red arrow will appear.
5. Move the arrow to one of the "Modes” (Free position) where you want to store the parameters by pressing the
POINT UP/DOWN BUTTON(s). Press the SELECT (REAR CLICK) BUTTON to select it.
NOTE; If "Stored" appears in all Modes, no new PC parameter data can be stored, in this case, clear the PC
parameter data using the Mode free Function,
y'iijo fC:
ill
ViA!N MENU DISPLAY
VGA 1
111
hhi-
l|l|!'
— 4 2 -
