HAND LIFT & SHEAVE
lEF
NO. PART
NO.
DESCRIPTION
o
o
03
a>
o
o
03
CM
03
1 029082 LIFT LEVER 1 1
2 029083 ROD 1 1
3 083104 SPRING 1 1
4 064096 WASHER, Special 1 1
5 075053 GRIP 1 1
6
029084 BRACKET 1 1
7 029090 LIFT PLATE 1 1
8 055082 BUSHING, Nylon 2 2
9 064097 WASHER, Special 1 1
10 029091 STRIP 1 1
11 029088 LIFT 1 1
12 029141 SPACER 2 2
13 029092 LINK 1 1
14 029096 PIN 1 1
15 029093 LINK, R.H. 1 1
16 029094 LINK,L.H. 1 1
17 55089 BUSHING 8 8
18 029095 LINK 2 2
19 029085 SHEAVE 1 1
20 64088 WASHER 2 2
21 029089 BEARING HOUSING 1 1
22 054073 BALLBEARING 2 2
23 029086 SHEAVE, PTO 1 1
24 064108 WASHER, Special (AR) (AR)
25 057012 SNAP RING 1 1
26 029087 BELT GUIDE 1 1
27 058034 ROLL PIN, 1/8" X 3/4" 1 1
28 062029 BOLT, Carriage 3/8"- 16 x 1" 4 4
29 064008 WASHER, Flat, 3/8" 14 14
30 063021 LOCKWASHER,3/8" 14 14
31 065018 NUT, Hex, 3/8"-16 14 14
32 067004 PIN, Cotter, 1/8" X 1" 6 6
33 062016 BOLT, Carriage, 3/8"- 16x1-1/4 " 2 2
34 059004 CAP SCREW, HH, 3/8"- 16x1" 4 4
35 059005 CAPSCREW, HH, 3/8" X 16 x
1-1/4" 4 4
36 066003 KEY, Woodruff, No. 9 1 1
37 059003 CAPSCREW, HH, 5/16"- 18x1 " 2 2
38 064002 WASHER, Flat, 5/16" 3 3
39 063003 LOCKWASHER,5/16" 3 3
40 065015 NUT, Hex, 5/16"-18 2 2
41 058050 PIN, Groove, 1/4" X 1-1/4"
Type E 1 1
42 059039 CAPSCREW 5/16"-18 X 1/2 1 1
43 069094 J-CLAMP 1 1
-
