REAR WHEELS & AXLE, BELT & DRIVE-HYDROSTATIC
REF
NO.
PART
NO.
DESCRIPTION
CM
o
0
01
CM
O)
REF
NO.
PART
NO.
DESCRIPTION
CM
o
o
O)
CM
O)
1 029265 IDLER ARM 1 29 029143 SPACER 1
2 055077 BEARING, Nylon 2 30 057061 RING, Retaining 1
3 083111 SPRING 1 31 057052 CLAMP, Spring 1
4 073054 IDLER 1 32 069096 CLAMP, Spring 1
5 010360 SPACER 1 33 064110 WASHER 2
6 029041 SHEAVE 1 34 058018 ROLL PIN, 3/16" x1" 1
7 029142 SPACER 1 35 059140 CAPSCREW, H.H. 5/16"-18x1-1/2
8 029043 FAN 1 Grade 5 1
9 064099 WASHER, Special 1 36 063021 L0CKWASHER,3/8" 6
'10 029042 SHIELD 1 37 065042 LOCKNUT, 5/16"-18 1
til
629010 DRIVE ASS'Y HYDROSTATIC 1 38 066006 KEY, Woodruff, No. 3 2
12 029044 GASKET 1 39 059132 CAP SCREW, HH, 1/4"- 20x1 1
*13 TRANSMISSION (Tecumseh No. 1 40 063002 LOCKWASHER, 1/4" 1
1309) 41 070009 FLANGE WHIZLOCKSCREW 4
629002 WHEEL ASS'Y, Rear ConsisU of: 2 43 059141 CAPSCREW, HH,3/8" -16x3" Grade 5 4
14 071102 RIM 1 44 059023 CAP SCREW. HH 3/8" -16 x 3/4" 2
15 071101 TIRE, 20x8.00-10 ,1 45 029105 SHEAVE 1
16 029160 SPACER 1 46 066026 KEY, Square, 1/4" x 1/4" x 2-1/2" 1
^ 17 072102 "V" BELT (Hydrostatic) 1 47 059142 CAPSCREW,HH.7/16" -20x1" 1
18 066018 KEY, Square, 1/4" x 1/4" x 1-3/4" 2 48 063005 LOCKWASHER, 7/16" 1
19 064029 WASHER, Special 2 49 064047 WASHER, Special 1
20 067027 COTTER, 'T" Head 2 50 029139 SPACER 1
21 029173 CAP, Grease 2 51 065039 LOCKNUT, 3/8"-16 1
22 023077 "U" BOLT 8i CLAMP ASS'Y 2 52 029217 DUMP VALVE 1
23 064002 WASHER, Flat, 5/16" 2 53 029215 NUT, W/Gasket 1
24 029045 RESERVOIR, Oil 1 54 056078 "0" RING 1
25 029001 CAP 1
55 056079 OIL SEAL 1
26 029138 CLIP 1
56 029216 GASKET 1
27 029135 HOSE 1
57
58 029214
057072 ADAPTOR
SNAP RING
1
1
28 029046 SPUR GEAR 1
59 054071 BEARING 1
*The transmission is to be serviced and warrantied by Tecumseh Products. 60 056095 SEAL 1
61 529014 INPUT SHAFT W/BEARING 8i SNAP RING1
t Assembiy includes Ref. No. 52 thru 62
62 054071 SNAP RING 1
63 012132 IDLER I
64 029264 PIVOT PIN 1
65 064123 WASHER 2
-25
