PTO LINKAGE, BELT & SHEAVE
REF
NO. PART
NO.
DESCRIPTION
o
0
CM
01
CM
e
e
a»
Oi
1 029098 HANDLE 1 1
2 075052 KNOB 1 1
3 029104 PIN
1 1
4 029103 SPACER
1 1
5 064105 WASHER, Special 1 1
6 029102 GUIDE TUBE 1 1
7 083114 SPRING
1 1
8 029097 ROD 1 1
9 083118 SPRING
1 1
10 029101 CLEVIS 1 1
11 055084 BUSHING 2 2
12 029100 SUPPORT 1 1
13 029099 lOLER PIVOT 1 1
14 064100 WASHER, Special 1 1
15 073101 IDLER 2 2
16 029136 BELTFINGER 1 1
17 029137 BELT FINGER
2 2
18 072101 "V"BELT 1 1
19 067004 PIN, Cotter, 1/8" X 1" 3 3
20 059149 CAP SCREW, HH, 3/8" -16
X 2-1/4" Grade 5 1 1
21 064008 WASHER, Flat, 3/8"
1 1
22 063021 L0CKWASHER,3/8" 4 4
23 065018 NUT, Hex, 3/8"-16 4 4
24 064007 WASHER, Flat, 1/4" 5 5
25 064002 WASHER, Flat, 5/16" 1 1
26 065015 NUT, Hex, 5/16"-18 3 3
27 065061 NUT, Hex Jam, 5/16"-18 1 1
28 067016 PIN, Cotter, 5/32" x1" 1 1
29 059068 CAP SCREW, HH, 3/8"-16x2" 1 1
30 64043 WASHER, Flat,3/8" 2
2
31 062012 BOLT, Carriage, 1/4" - 20 x 3/4" 4 4
32 063002 L0CKWASHER,1/4" 4 4
33 065032 NUT. Hex. 1/4"-20 4 4
34 059041 CAPSCREW, HH.1/2"-13x2-1/4' ' 1 1
35 062006 BOLT, Carriage, 1/2" -13 x 2-1/2" 1 1
36 064120 WASHER, Flat, 1/2"
1 1
37 063006 LOCKWASHER, 1/2"
1 1
38 065021 NUT. Hex, 1/2" 1 1
39 064094 J-CLAMP
1 1
40 064047 WASHER, Flat, 1/2"
2 2
41 065097 LOCKNUT, Hex, 1/2"-13 1 1
42 062029 BOLT, Carriage, 3/8"- 16x1"
2 2
43 064102 WASHER, Special 2 2
44 075055 GROMMET 1 1
-
33
-
