REAR WHEELS & AXLE, BELT & DRIVE -GEAR
REF
NO.
PART
NO.
DESCRIPTION
o
0
01
PM
o»
REF
N0.
PART
NO.
DESCRIPTION
o
e
o>
O)
1
029028
IDLER ARM
1
33
059005
CAP SCREW, HH, 3/8" - 16 x M/4"
2
2
029140
SPACER
2
34
064008
WASHER, Flat, 3/8"
6
3
029029
IDLER ARM
1
35
063021
LOCKWASHER,3/8"
8
4
064101
WASHER, Special
1
36
065018
NUT, Hex, 3/8"-16
8
5
073101
IDLER
2
37
059143
CAP SCREW, HH, 1/2" x 2-1/4" Gr. 5
1
6
083110
SPRING
1
38
059058
CAP SCREW, HH, 1/2" -13 x 3-1/4"
1
7
073064
SHEAVE
1
Grade 5
8
629003
SHEAVE W/Ball Bearing
1
39
064120
WASHER, Flat, 1/2"
2
9
054073
BALLBEARiNG
2
40
063006
LOCKWASHER, 1/2"
2
10
064108
SPACER, Washer
3 (AR)
41
065021
NUT, Hex, 1/2"-13
2
11
029034
IDLER PIVOT
1
43
066003
KEY, Woodruff, No. 9
1
12
055077
BEARING, Nylon
2
44
060030
SCREW, Hex Socket, 1/4" - 20 x 5/8"
2
13
029035
SUPPORT
2
45
065099
NUT, Hex Jam, 1/4"-20
2
14
083117
SPRING
1
46
072103
"V" BELT
1
15
029039
BELT GUIDE
2
47
067006
PIN, Cotter, 3/16"
X
1-1/4"
1
16
064102
WASHER, Special
4
48
059004
CAPSCREW,.3/8"- 16x1"
2
17
064110
WASHER
2
49
059158
B0LT,Tap,3/8"- 16
X
1-3/4"
2
18
029036
BELT GUIDE
1
50
064002
WASHER, Flat, 5/16"
2
19
059022
CAPSCREW, HH, 5/16’’- 18x3/4"
1
51
063003
LOCKWASHER, 5/16"
2
20
029031
STRAP
1
52
065015
NUT, Hex, 5/16"-18
2
21
072100
"V" BELT
1
53
062011
BOLT, Carriage, 5/16"- 18x3/4"
1
*22
TRANSAXLE'Tecumseh No. 1212
1
54
059023
CAPSCREW, HH, 3/8"-16x3/4"
2
\
629002
WHEEL ASS’Y, Rear, ConsisU of
55
029105
SHEAVE
1
23
Q71102 RIM
1
56
066026
KEY,Square, 1/4"
X
1/4"
X
2-1/2"
1
24
071101 TIRE, 20x 8.00- 10
1
57
059142
CAP SCREW, HH, 7-1/16" - 20 UNF
25
065039
LOCKNUT, 3/8" *16
1
X
1"
1
26
029160
SPACER
1
58
063005
LOCKWASHER, 7/16"
1
27
066018
KEY, Square, 1/4"
X
1/4"
X
1-3/4"
2
59
064047
WASHER, Special
1
28
064029
WASHER, Special
2
60
029139
SPACER
1
29
067027
COTTER,'T'Head
2
61
073054
IDLER
1
30
029173
CAP, Grease
2
62
029263
BRACKET
1
31
023077
CLAMP ASS'Y
2
63
059069
CAPSCREW 5/16"-18x1-1/4
1
32
064002
WASHER, Flat, 5/16"
2
64
075026
GROMMET
2
65
064007
WASHER
1
*The Transaxle is to be serviced and warrantied by Tecumseh Products
66
065042
LOCKNUT 5/16"-18
1
