FRAME, STEERING, FRONT AXLE, FRONT WHEEL & SPINDLE
REF
NO.
PART
NO.
DESCRIPTION
o
e
o>
a>
O
O
O)
CM
O)
REF
NO.
PART
N0.
DESCRIPTION
o
o
cn
CM
O)
CM
o
o
O)
CM
O)
1
029002
FRAME, Gear
1
33
075059
WASHER, Thrust
2
2
529009
FRAME, Hydrostatic
1
34
029013
LOCK STRIP
2
2
2
029158
L.H. BALL JOINT
2
2
35
029024
WASHER, Spring
4
4
3
629007
STEERING WHEEL W/Cap
1
1
36
029015
LATCH, L.H.
1
1
4
029163
CAP
1
1
37
029014
LATCH, R.H.
1
1
5
029020
STEERING COLUMN
1
1
38
029018
BRACKET
1
1
6
029023
SPACER
1
1
39
058004
PIN, Spring, 1/4"
X
1-1/2"
1
1
7
054025
BEARING, Side Flange
1
1
40
067006
PIN, Cotter, 3/16"
X
1-1/4"
2
2
8
029021
PINION GEAR
1
1
41
059003
CAPSCREW, HH, 5/16"-18
X
1
2
2
9
029133
NEEDLE ROLLER
1
1
42
064002
WASHER, Flat, 5/16"
2
2
10
064095
WASHER, Special
3(AR)3
43
063003
LOCKWASHER,5/16"
4
4
11
055076
BUSHING' Nylon
1
1
44
065015
NUT, Hex, 5/16"-18
4
4
12
055030
BUSHING
1
1
45
063021
LOCKWASHER,3/8"
13
13
13
055083
BUSHING, Hex Bore
2
2
46
065018
NUT, Hex, 3/8"-16
7
7
14
029017
ARM 8i SHAFT
1
47
062005
BOLT, Carriage, 3/8" -16 x 2-1/2"
4
4
15
064111
WASHER, 7/8" I.D.x 1-1/4" 0.0,
2
2
48
059133
CAP SCREW, HH, 3/8" -16 x 1-1/4 "2
2
16
029019
BEVEL GEAR SEGMENT
1
1
Grade 5
17
029012
LINK
1
1
49
062012
BOLT, Carriage, 1/4" - 20 x 3/4"
1
1
18
029010
CRANK
1
1
50
063002
L0CKWASHER,l/4"
1
1
19
029011
BLOCK
4
4
51
065032
NUT, Hex, 1/4"-20
1
1
20
029007
MOUNTING, Front
1
1
52
022093
FITTING, Grease
2
2
21
029006
AXLE PIVOT
1
53
058050
PIN, Grooved, 1/4" x 1-1/4" Type E 2
2
22
029005
AXLE, Front
1
j
54
065005
NUT, Hex, 3/8"
X
24 UNF.
6
6
23
029008
SPINDLE, L.H.
1
1
55
065073
NUT, Hex, 3/8"-24 UNF L.H.
2
2
24
029009
SPINDLE, R.H.
1
1
56
059004
CAP SCREW, HH, 3/8"-16x1"
3
3
25
064109
WASHER, Special
4
4
57
065039
LOCKNUT, Hex, 3/8"-16
2
2
26
067027
COTTER, "T" Head
2
2
58
064043
WASHER, Flat, 3/8"
4(AR)4
27
029173
GREASE CAP
2
2
59
067024
PIN, Cotter, 1/8"
X
3/4"
2
2
629001
WHEEL ASS'YIConsisU of)
2
2
60
062029
BOLT, Carriage, 3/8"-16x1"
2
2
28
055086 BUSHING
2
2
61
059128
CAPSCREW, HH, 5/16"-18
X
2
2
29
071099 TIRE, 15x6.00
1
1
1-3/4" Grade 5
30
071100 WHEEL
1
1
62
064008
WASHER, Flat, 3/8"
3
3
31
029171
BALL JOINT, R.H.
2
2
63
064041
WASHER
1
1
32
029016
TIE ROD
2
2
64
064102
WASHER
1
1
65
059004
CAPSCREW
1
1
-21
