Attachments
ITEM
N0. DESCRIPTION
ITEM
N0. DESCRIPTION
1 Cotter Pin 1/8 X 1" 30 Front Lift Adapter
2 Shoulder Bolt 31 Mower Pan
3 Yoke 32 Plate
4 Link Rod 33 Retainer Hub
5 Yoke Lift Lever 34 Cap Screw 3/8-16 x 1 H.H.
6 Lockwasher 3/8 35 Blade Tray
7 Screw Pin 36 Mower Blade
8 Snap Ring 37 Lockwasher 3/4
9 Snap Ring 38 Nut
10 Ball Bearing 39 Reinforcing Strip
11 Roll Pin 1/8x1" 40 Nut 5/16-18
12 Woodruff Key No. 9 41 Shoulder Bolt
13 Mower Spindle 42 Chute
14 Nut 3/8-16 Hex 43 Hinge Pin
15 Nut 3/8-16 Locknut 44 Bushing
16 Bearing Slinger 45 Spring
17 Belt 46 Cotter Pin
18 Spindle Sheave 47 Spacer
19 Bearing Housing 48 Cap Screw 2-1/4-20 X 1/2
20 Lockwasher 5/16 49 Hex Nut 3/8-24
21 Ball Bearing 50 Hex Connector
22 Mower Spindle Housing 51 Lockwasher
23 Height Control Plunger 52 Lug Nut
24 Shift Ball 53 Locknut 5/16-18 X 2"
25 Roll Pin 1/4 X 1-1/4 54 Cap Screw 5/16-18 x 1/2
26 Height Adjustment Quadrant 55 Mulcher Kit
27 Spring 56 Z-Bolt
28 Adapter Pin 57 Washer
29 Front Adapter Pin 58 Mulcher Bracket
10.2 Rotary Mower Lubrication
Remove belt guard on mower and lubricate spline
shaft on which mower driven sheave is located.
This sheave is to be free to move up and down when
height of mower is moved up and down.
Gear Case - Check gear case oil level approximately
every 8 hours of operation. Oil level should be
within 1/4" of filler hole. Drain and refill gear case
every 100 hours of operation or once each season.
Use Ariens special gear lubrication L-2 (Part No.
000080) (approximately 8 ounces).
Caster Wheel Assembly - Grease fittings are pro­
vided on top of caster wheel swivel shaft and on axle
bolt. Grease these four fittings approximately every
8 hours of operation.
