Speed Selector And Wheels
I T E M
N O .
D E S C R I P T I O N
I T E M
N O .
D E S C R I P T I O N
1
Snap Ring Ext. 1/2
16
Lower Shift Rod
2
Knob
17
Shift Arm Lever
3
Rod
18
Frame
4
Extension Spring
19
Bottom Cover
5
Pivot
20
Spindle Cup
6
Lock Nut 5/16-18
21
Push Nut or Cotter Pin
7
Lock Nut 1/4-20
22
Wheel Assembly
8
Cap Screw 1/4-20
X
1"
23
Hub Cap
9
Cap Screw 5/16-18 x 2-1/2
24
Taptite 1/2-20 x 5/8
10
Cotter Pin 1/8
X
3/4
25
Cap Screw 5/16-18 x 1/2
11
Upper Shift Rod
26
Shift Lever Bracket
12
Nut 5/16-24
27
Taptite 5/16-18
X
1/2
13
Cotter Pin 3/32
X
3/4
28
Cap Screw 5/16-18 x 3"
14
Shift Link
29
Spacer
15
Clevis Pin
3-3
