Ariens 924 - Manual (Page 65)

Attachments
ITEM
N0. DESCRIPTION
ITEM
N0. DESCRIPTION
1 Nut 5/16-18 44 Roll Pin 3/16 X 1-1/2
2 Lock Washer 5/16 45 U-Joint
3 Set Screw 1/4-20 46 Drive Shaft
4 Bearing 47 Sprocket
5 Carriage Bolt 5/16-18 x 3/4 48 Stiffener Plate
6 Cap Screw 1/2-13 x 1" 49 Hub
7 Lock Washer 1/2 50 Sheave
8 Retainer Plate 51 V-Belt
9 Brush Selection (Poly) 52 Lock Nut 5/16-18
10 Cap Screw 3/8-16 x 3-1/2 53 Set Screw
11 Cap Screw 3/8-16 x 3" 54 Ribbed Neck Bolt 5/16-18 x 3/4
12 Hood 55 Cap Screw 3/8-16 x 1-1/4
13 Core 56 Gear Box
14 Cap Screw 5/16-18 x 1" 57 Adapter Frame
15 Washer 5/16 58 Retainer Nut
16 Chain 59 Lock Screw 3/8-16 x 3/4
17 Locknut 3/8-16 60 Woodruff Key 3/16x5/8x5/16
18 Idler Arm 61 Sprocket
19 Bushing 62 Chain
20 Cap Screw 3/8-16 x 2" 63 Extension Spring
21 Chain Tightener 64 Shift Ball
22 Washer 3/8 65 Position Rod
23 Spring 66 Position Support Bracket
24 Lock Washer 3/8 67 Lock Nut 5/16-18
25 Shaft Guard 68 Lock Screw 5/16-18 x 3/4
26 Brush Frame 69 Carriage Bolt 5/16-18 x 1-3/8
27 Speed Nut 5/16-18 70 Release Rod
28 Chain Shield 71 Clamp
29 Cap Screw 3/8-16 x 1" 72 Spacer Bushing
30 Lock Nut 3/8-16 73 Washer 5/16
31 Lock Nut 3/8-16 74 Bottom Mount
32 Castor Leg 75 Latch Bar
33 Castor 76 Hood Strap
34 Cap Screw 5/16-18 x 3/4 77 Cap Screw 5/16-18 x 1-1/4
35 Shaft 78 Top Mount
36 Bearing Flange 79 Washer 21/64
37 Bearing 80 Spring
38 Washer 81 Belt Retainer
39 Roll Pin 3/16x1-3/4 82 Cap Screw 1/4-20 x 1/2
40 Sprocket 83 Lock Nut 1/4-20
41 Spacer 84 Lock Nut 3/8-16
42 Nut 5/16-18 85 Mounting Plate
43 Cap Screw 3/8-16 86 Washer 11/32
NOTE: Installation of belt retainer required when
brush model 824004 is to be mounted on sno-thro
tractor models 924040 and 924050.
10.1 Caster Wheels
Caster Wheels - Adjust the caster wheels by loosen­
ing the cap screw on each side of brush and sliding
the caster wheel support up or down as required.
Casters must be adjusted so that brush cleans
properly, but does not "dive" into the grass and
stall the tractor.
