Ariens 924 - Manual (Page 35)

Reduction Drive
I T E M
N O . D E S C R I P T I O N
I T E M
N O . D E S C R I P T I O N
1 Taptite 1/4-20 x 3/8 31 Pinion and Sprocket
2 Shaft Support 32 Bushing
3 Bearing Retainer 33 Zerk Fitting
4 Ball Bearing 1-1/8 I.D. 34 Differential or Spur Gear
5 Washer 7/8 35 L.H. Axle
6 Rib Neck Bolt 1/4-20 x 1/2 36 Bushing
7 Lock Nut 1/4-20
37 Lock Washer Ext. 1/4
8 Hex Shaft
38 Zerk Fitting
9 Woodruff Key 1/8 x 5/8 x 1/4
39 Bushing
10 9 Tooth Sprocket
40 Groove Pin 1/4 X 1-3/4
11 Idler Chain
41 Lockout Hub Assembly
12 Washer 17/32 42 Roll Pin 3/32 X 1"
13 Bearing Flange
43 Knob
14 Ball Bearing 1/2 I.D.
44 Lockout Hub
15 Bearing Flange
45 Compression Spring
16 Lock Nut No. 10-24 46 Pin
17 Lock Nut 1/2-20 47 Wheel Hub
18 Nut 3/8-16
48 Washer 3/4
19 Lock Washer 3/8 49 Roll Pin 3/16 X 1-1/4
20 Washer 3/8 50 Cotter Pin 1/8 X 1-1/4
21 Reduction Shaft 51 Feather Key 3/16 x 1-1/4 x 3/16
22 Bushing 52 Axle Shaft
23 Reduction Sprocket (Double or Single) 53 Woodruff Key 1/4x3/4x5/16
24 Shaft Support 54 Roll Pin 3/16 X 1-1/2
25 Taptite 1/4-20 x 1/2 55 R.H. Axle
26 Washer 5/8
27 Pinion Shaft
28 Roll Pin 5/32x1"
29 Roll Pin 1/8 X 1"
30 Pinion Chain
5-3
