Gear Case
Cast Iron
ITEM
NO.
DESCRIPTION
ITEM
NO.
DESCRIPTION
1
Roll Pin 5/16
X
1-3/4
18
Dust Cap
2
Fan
19
Roll Pin 3/16
X
1-1/2
3
Woodruff Key 3/16x7/8x3/8
20
Gear Case
4
Worm Shaft
21
Bushing
5
Straight Key 3/16 x 1" x 3/16
22
Washer 1-5/8
6
Adjusting Plug
23
Woodruff Key 1/4
X
7/8
X
3/8
7
Seal
24
Gear Case Shaft
8
Bearing Cup 1-25/32 O.D.
25
Gasket
9
Bearing Cone 3/4 I.D.
26
Gear Case Cover
10
Bearing Spacer
27
Lock Washer Int. 1/4
11
Worm & Gear
28
Cap Screw 1/4-20 x 3/4
12
Snap Ring Int. 1-25/32
29
Rake Shaft
13
Seal 1-5/8
30
Gear Case Assembly
14
Pipe Plug
Requires 5 oz. L-2 Special Gear
15
Washer 21/64
Lube Part No. 000080
16
Lock Washer 5/16
31
L-2 Special Gear Lube
17
Cap Screw 5/16-18 x 3/4
16 oz. Bottle
8-3
