Attachments
ITEM
N0. DESCRIPTION
ITEM
NO. DESCRIPTION
1 Cotter Pin 1/8 X 1" 45 Pinion Shaft
2 Lockwasher 3/8-.145 x .115 46 Snap Ring
3 Ball Bearing 47 Bearing Spacer
4 Woodruff Key No. 9 48 Bevel Pinion and Gear
5 Nut 3/8-16 Hex Full Plated 49 Pipe Plug 3/8 Square Head
6 Bushing 50 Setscrew 1/4-20 x 1/2 Socket Head
7 Washer 1/4 Wrought Plated 51 Expansion Plug
8 Lockwasher 5/16-.130 x .097 52 Gear Case
9 Cap Screw 5/16-18 x 3/4 H.H. 53 Gasket
10 Link Rod 54 Gear Shaft
11 Lockwasher 3/4-.234 x .188 55 Roll Pin 5/16 X 1-1/4
12 Nut 3/4-10 Hex Jam Plated 56 Woodruff Key No. 11
13 Nut 5/16-18 Hex Plated 57 Snap Ring
14 Flange Whiziock Screw 5/16-18 x 1/2 58 Bearing Flange
15 Rear Lift Adapter 59 Seal
16 Rear Adapter Pin 60 Brake, w/Lining
17 Belt Guard 61 Setscrew, 5/16-18 x 3/8 Socket Head
18 Snap Ring 62 Mounting Bracket
19 Frame 63 Cap Screw 3/8-16 x 1 -1/4
20 Washer .754 I.D. x 1" O.D. x .032 64 Flange Whiziock Screw 3/8-16 x 1/2
21 Zerk Fitting 66 Nut 3/8-16 Hex Jam Plated
22 Washer 67 Washer 7/8
23 Caster Fork 68 Cotter Pin
24 Axle Bolt 69 Shield
25 Washer 1" 70 Extension Strip
26 Caster Wheel 71 Carriage Bolt 1/4-20
27 Belt Small Wheel Tractor 72 Locknut 1/4-20
28 Spring 73 Clevis Pin
29 Drive Sheave 74 Nut
30 Swivel Bracket 75 Arm Extension
31 Snap Ring 76 Cap Screw 1/4-20 x 1/2
32 Washer 77 Locknut 1/4-20
33 Cap Screw 5/16-18 x 1-3/4 78 Twin Whiz Locknut 5/16-18
34 Spacer 79 Brake Lining
35 Pulley 80 Rivet
36 Lower Mounting Bracket 81 Gear Case Assembly
37 Upper Mounting Bracket 82 Cap Screw 3/8-16 x 3/4
38 Cap Screw 83 Hub
39 External Tooth Lockwasher 84 Ribbed Neck Bolt
40 Spring 85 Flange Whiziock Nut
41 Idler Arm 86 Hairpin
43
44
Pulley
Roll Pin, 1/4x1"
87 Clevis Pin
