24

| PIR Ready VT7600 Series-Installation Guide

028-0363-02

Cal OS

Outside air temperature

sensor

calibration

Default value =

0.0 °F

or °C

Offset that can be added/subtracted to the actual dis-

played outdoor temperature.
± 5.0 °F, (± 2.5 °C)

H stage

Number of heating

stages.

Applicable to 2 stage

models only

Default value =

2

stages

Will revert the operation of 2 stages Terminal Equip-

ment Controller to single stage operation only when the

second heating step is not needed.

1 or 2 stages
For heat pump models, H stage is limited to 1 stage

only (W1 – Aux. Heat)

C stage
Number of cooling

stages

Default value =

2

stages

Will revert the operation of 2 stage Terminal Equipment

Controller to single stage operation only when the sec-

ond cooling step is not needed.

1 or 2 stages

H lock
Outside air temperature

heating lockout
Default value =

120 °F

(49 °C)

Disables heating stage operation based on outdoor air

temperature.

Function will only be enabled if OS (outside air tempera-

ture sensor) is connected.

From -15 °F up to 120 °F (-26 °C up to 49 °C)

C lock
Outside air temperature

mechanical cooling

lockout.
Default value =

-40 °F

(-40 °C)

Disables cooling stage operation based on outdoor air

temperature.

On economizer model, free cooling will not be disabled

by this function.

Function will only be enabled if OS (outside air tempera-

ture sensor) is connected.

From -40 °F up to 95 °F ( -40 °C up to 35 °C )

Unocc TM
Unoccupied Timer value
Default

0.5 hours

Time delay between the moment where the Terminal

Equipment Controller toggles from occupied to unoccu-

pied after the last movement has been detected by the

PIR.
Range is:

0.5 to 24.0 hours in 0.5 hour increments
