| PIR Ready VT7600 Series-Installation Guide
028-0363-02
Ex. #1 Four event retail establishment schedule
Event Period #1 -
Event #1
Period #1 -
Event #2
Period #2 -
Event #3
Period #2 -
Event #4
Occupied Unoccupied Occupied Unoccupied
Setpoint
Cool
72 °F
Heat
70 °F
Cool
80 °F
Heat
62 °F
Cool
72 °F
Heat
70 °F
Cool
80 °F
Heat
62 °F
Daily
Occupancy
Monday 7.00 AM 5.00 PM 12.00 PM * 12.00 PM * Day time only
Tuesday 7.00 AM 5.00 PM 12.00 PM * 12.00 PM * Day time only
Wednesday 7.00 AM 5.00 PM 12.00 PM * 12.00 PM * Day time only
Thursday 7.00 AM 5.00 PM 7.00 PM 10.30 PM Day/evening time only
Friday 7.00 AM 5.00 PM 7.00 PM 10.30 PM Day/evening time only
Saturday 12.00 PM * 12.00 PM * 12.00 PM * 12.00 PM * Occupied
Sunday 12.00 PM * 12.00 PM * 12.00 PM * 12.00 PM * Occupied
* Programming events to the same time will cancel the last period and leave the controller
in unoccupied mode
Ex. #2 Residential
Event Period #1 -
Event #1
Period #1 -
Event #2
Period #2 -
Event #3
Period #2 -
Event #4
Occupied Unoccupied Occupied Unoccupied
Setpoint
Cool
72 °F
Heat
70 °F
Cool
80 °F
Heat
62 °F
Cool
72 °F
Heat
70 °F
Cool
80 °F
Heat
62 °F
Daily
Occupancy
Monday 6:00 AM 8:00 AM 4:00 PM 10:00 PM Day/evening time only
Tuesday 6:00 AM 8:00 AM 4:00 PM 10:00 PM Day/evening time only
Wednesday 6:00 AM 8:00 AM 4:00 PM 10:00 PM Day/evening time only
Thursday 6:00 AM 8:00 AM 4:00 PM 10:00 PM Day/evening time only
Friday 6:00 AM 8:00 AM 4:00 PM 11:30 PM Day/evening time only
Saturday 8:00 AM ** 8:00 AM ** 8:00 AM ** 11:59 PM ** Day time only
Sunday 12:00 AM ** 12:00 AM ** 12:00 AM ** 11:59 PM ** Occupied all day
** Programming consecutive events to the same time will cause the controller to choose
the last event as the time at which it will set its schedule. In the above example for
Saturday, the controller will control to the occupied set point from 8:00 AM until 11:59
PM. Since it is desired to be in occupied mode throughout the night, then it is neces-
sary to program the first event on Sunday at 12:00 AM. The controller will force a one
minute unoccupied period for a one minute period (between 11:59 PM and 12:00 AM on
Saturday).
