Outdoor air temperature

• Outdoor air temperature display is only enabled when outdoor air temperature

sensor is connected.

• A maximum range status display of 50 °C (122 °F) indicates a shorted sensor.

Associated functions, such as mode lockouts and economizer function are

automatically disabled.

• A minimum range status -40 °C (-40 °F) is not displayed and indicates a opened

sensor or a sensor not connected. Associated functions, such as mode lockouts

and economizer function are automatically disabled.

Alarms

• If alarms are detected, they will automatically be displayed at the end of the

status display scroll.

• During an alarm message display, the back lit screen will light up at the same

time as the message and shut off during the rest of the status display.

• Two alarms maximum can appear at any given time.
• The priority for the alarms is as follows:

Sequence of manual-scroll status display:
Manual scroll of each menu item is achieved by pressing the Yes (scroll) key re-

petitively. The last item viewed will be shown on the display for 30 seconds before

returning to automatic scrolling. Temperature is automatically updated when scrolling

is held.

Clock Status

System

Mode

Schedule

Status

Outdoor

Temperature

Alarms

(if detected)

Monday

12:00 AM

Sys Mode

Off

Occupied

Outdoor

xx.x °C or °F

Frost ON

Sys Mode

Auto

Unoccupied

SetClock

Sys Mode

Cool

Override

DAS Alarm

Sys Mode

Heat

FA Alarm

High CO2

Frost ON

Indicates that the heating is energized by the low limit frost protec-

tion room temperature setpoint 5.6 °C (42 °F).

SetClock

Indicates that the clock needs to be reset. There has been a power

failure which has lasted longer than 6 hours.

DAS Alarm

Indicates that the discharge air temperature is either too low or too

high.

FA Alarm

Indicates that the Fresh Air Level is either too low or too high.

High CO2

Indicates that the CO2 Level value is higher than the Max CO2

parameter value.
