20
| PIR Ready VT7600 Series-Installation Guide
028-0363-02
Channel
Channel selection
Default value = 10
Range is: 10 to 26
Conditional parameter to Wireless models
VT76xxX5x00W
This parameter will only appear when a wireless net-
work adapter is present. If the Terminal Equipment Con-
troller is installed as a stand-alone (Network Ready) unit
or with a BACnet® or Echelon® adapter, this parameter
will not be used or displayed.
This parameter (Channel) is used to link specific
Terminal Equipment Terminal Equipment Controllers
to specific Viconics wireless gateway(s) (VWG). For
every Terminal Equipment Terminal Equipment Control-
ler reporting to a gateway (maximum of 30 Terminal
Equipment Controllers per gateway), be sure you set
the SAME channel value both on the gateway and the
Terminal Equipment Controller(s).
Viconics recommends using only channels 15 and
25.
The default value of 10 is NOT a valid channel. The
valid range of available channel is from 11 to 26
AI1
Analog input no.1 con-
figuration
Default value = None
None, No function will be associated with the input
CO2, the 0-10VDC input value is used as a 0-2000ppm
CO2 level:
0 VDC = 0ppm
10VDC = 2000ppm
FA Range
FA range upper limit
value
Default value =
0 CFM
Sets the upper limit of the CFM range. This parameter
should be set based on the rooftop unit size. If set to 0
CFM, the fresh air damper control will be based on the
Min/Max CO2 and Min/Max Pos values. See Damper
Position section for more details.
0 to 20 000 CFM (0 to 9438 L/s), 10 or 100 incre-
ments
MenuScro
Menu scroll
Default value = On =
Scroll active
Removes the scrolling display and displays the room
temperature/humidity to the user. With this option
enabled, no mode, schedule and outdoor temperature
status is given.
▪ On = Scroll active
▪ Off = Scroll not active
Lockout
Keypad lockout levels
Default value = 0 No
lock
0 = No lock
1 = Low level
2 = High level
