19
| PIR Ready VT7600 Series-Installation Guide
028-0363-02
CONFIGURATION
PARAMETERS
DEFAULT VALUE
SIGNIFICANCE AND ADJUSTMENTS
PswrdSet
Configuration parameters
menu access password
Default value = 0
Range is: 0 to 1000
This parameter sets a password access to prevent
unauthorized access to the configuration menu param-
eters. A default value of “0” will not prompt a password
or lock the access to the configuration menu.
Range is: 0 to 1000
Com addr Thermostat
networking address
Default value = 254
Range is: 0 to 254
Conditional parameter to BACnet MS-TP models
(VT76xxX5x00B)
Conditional parameter to Wireless models
(VT76xxX5x00W)
This parameter will only appear when a BACnet or wire-
less network adapter is present. If the thermostat is in-
stalled as a stand-alone unit or with an Echelon adapter,
this parameter will not be used or displayed
- For BACnet MS-TP models valid range to use is
from 1 to 127. Default value of 254 disables BACnet
communication for the thermostat.
- For wireless models valid range is 0 to 254 with a
maximum of 30 thermostat per VWG
PAN ID
Personal Area Network
Identification
Default value = 0
Range is: 0 to 500
Conditional parameter to Wireless models
VT76xxX5x00W
This parameter will only appear when a wireless net-
work adapter is present. If the Terminal Equipment Con-
troller is installed as a stand-alone (Network Ready) unit
or with a BACnet® or Echelon® adapter, this parameter
will not be used or displayed.
This parameter (Personal Area Network Identification)
is used to link specific Terminal Equipment Controllers
to a single specific Schneider-Electric wireless gateway
(VWG). For every Terminal Equipment Controller report-
ing to a gateway (maximum of 30 Terminal Equipment
Controllers per gateway), be sure you set the SAME
PAN ID value both on the gateway and the Terminal
Equipment Controller(s).
The default value of 0 is NOT a valid PAN ID. The valid
range of available PAN ID is from 1 to 500.
