Typical examples of a 2 event office schedule
Ex. #1 Office building closed all weekend

Event

Period #1 - Event #1 Period #1 - Event #2

Occupied

Unoccupied

Setpoint

Cool

72 °F

Heat

70 °F

Cool

80 °F

Heat

62 °F

Daily

Occupancy

Monday

7.00 AM

6.00 PM

Day time only

Tuesday

7.00 AM

6.00 PM

Day time only

Wednesday

7.00 AM

6.00 PM

Day time only

Thursday

7.00 AM

6.00 PM

Day time only

Friday

7.00 AM

6.00 PM

Day time only

Saturday

12.00 PM *

12.00 PM *

Unoccupied

Sunday

12.00 PM *

12.00 PM *

Unoccupied

* Programming consecutive events to the same time will cause the thermostat to choose

the last event as the time at which it will set its schedule. In the above example, the

thermostat will control to the unoccupied set point until 7:00 AM Monday.

Ex. #2 Office building open all weekend

Event

Period #1 - Event #1 Period #1 - Event #2

Occupied

Unoccupied

Setpoint

Cool

72 °F

Heat

70 °F

Cool

80 °F

Heat

62 °F

Daily

Occupancy

Monday

7.00 AM

6.00 PM

Day time only

Tuesday

7.00 AM

6.00 PM

Day time only

Wednesday

7.00 AM

6.00 PM

Day time only

Thursday

7.00 AM

6.00 PM

Day time only

Friday

7.00 AM

6.00 PM

Day time only

Saturday

12.00 AM

11.59 PM **

Occupied

Sunday

12.00 AM

11.59 PM **

Occupied

** To program a day as occupied for 24 hours, set that day Occupied time to 12:00 AM and

Unoccupied time to 11:59 PM There will be a 1 minute unoccupied period every night at

11:59 PM with this schedule configuration.

Note: 12:00 PM = Noon

12:00 AM = Midnight
