Tuffy Security 142 - Manual

Page 1 of 6 - 3/6/2009 – Rev030609
INSTALLATION INSTRUCTIONS
Single Compartment Overhead Console #142
Please read and fill out the enclosed warranty registration card to activate your warranty.
Shipment Contents
#12 Top Panel Slide Assembly #1 Electronics Mounting Bracket #4 Clamp Bracket
#8 Windshield Mounting Bracket #7.9 Wire Clamp #7.20 Wire Loom #9.15 Rubber Seal
#9.13 10-32x3/4 Knob Screw #7.13 (2) ¼-20x1 Screw #7.19 (7) 10-32x1/2 Allen Screw #7.10 (4) 10-32x1/2 Hex Screw
#7.14 (2) ¼-20 Nylock Nut #7.3 (4) 10-32 Nylock Nuts #7.11 (3) 10-32 Flange Nuts (7.15) ¼” Washers
#7.2 (5) #10 Washers #7.1 (2) 1” Grommets
TOOLS / PARTS NEEDED
• T-25 Torx wrench
• 1/8” Allen Wrench or socket
• 5/32” Allen Wrench or socket
• 5/16” Wrench and/or socket
• Ratchet and 3/8” socket, 7/16” socket, & 10mm socket
• Black Electrical tape
• Any electrical wires, connectors, etc. to install electronic equipment. (Read completed instructions prior to making this
list of parts to avoid unnecessary trips to the store)
