ISOBUS Job Computer : IC18 Spreader European
Home Screen
The Home Screen gives access to the IC18’s available functions: Operation Mode, Transport Mode and Main Setup.
• To view the Home Screen, select HOME KEY in the top right corner of any screen.
Figure 3-4: Home Screen Home Key on Main Setup Screen
COUNTERS
The Counters Menu provides an overview of various system counters including Trip Counters, Campaign Counters and Total Counters.
From this screen one can also Export Counters.
MAIN SETUP MENU
| | | | | |
Counters Job Parameters Machine User Interface Communication Help
Trip
Campaign
Total
Export Counters
Figure 3-5: Counters
1. From the Main Setup Screen , select COUNTERS.
2. Select from:
►Trip – used to display information regarding area, distance, time and amount
applied
►Campaign – used to display information regarding area, amount applied and
time for all trips
►Total – used to display information regarding area, amount applied, and time
for all activity
►Export Counters – allows counter information to be exported in HTML or
CSV format
NOTE: Settings are NOT automatically saved when selected. The
ACCEPT KEY must be selected to save the setting. Select the
ESCAPE KEY to escape without saving settings and return to
the previous menu.
